Контроллер Dahua EAC10-P
Арт. DH-EAC10-P
10-портовый беспроводной контроллер точек доступа с PoE, до 10 устройств
Питание
Внешний БП 54 В (DC), 1.33 А
Сетевой интерфейс
(8) GbE (PoE), (2) GbE
PoE интерфейс
(8) PoE-out
Размеры, мм
190 × 97.5 × 29.5 мм
Вес, г
460
Минимальная рабочая температура, °C
-20
Максимальная рабочая температура, °C
55
15 968 ₽
Нашли дешевле?
Хочу в подарок
10-портовый беспроводной контроллер точек доступа с PoE, до 10 устройств
- Беспроводной контроллер точек доступа
- Поддержка нескольких глобальных портов (Multi-WAN)
- Управление точками доступа серии EAP
- Гибкие режимы преобразования сетевых адресов
- Функции интеллектуального роуминга
- Различные методы сетевой аутентификации
| PoE Power Supply | Yes |
| PoE Power | Full load: 64 W |
| Ethernet Port | 10 |
| Ethernet Port Speed | 10/100/1000 Mbps |
| Description of Function Slots | Port 1-8: 8 × 10/100/1000Base-T RJ-45/PoE Out Port 9-10: 2 × 10/100/1000Base-T RJ-45 |
| LAN Port | 9 × 1000 Mbps (1 LAN port can be switched to WAN port) |
| WAN Port | 1 × 1000 Mbps |
| Reset Button | 1 |
| Power Supply |
| PoE Power Supply | Yes |
| PoE Power | Full load: 64 W |
| Ethernet Port | 10 |
| Ethernet Port Speed | 10/100/1000 Mbps |
| Description of Function Slots | Port 1-8: 8 × 10/100/1000Base-T RJ-45/PoE Out Port 9-10: 2 × 10/100/1000Base-T RJ-45 |
| LAN Port | 9 × 1000 Mbps (1 LAN port can be switched to WAN port) |
| WAN Port | 1 × 1000 Mbps |
| Reset Button | 1 |
| Power Supply | External power supply: 54 VDC, 1.33 A |
| Power Consumption | Idling: 8 W Full load: 72 W |
| Protection | IP20 |
| Function | |
| 802.11 LAN Protocols | 802.11n;802.11b;802.11ax;802.11a;802.11g;802.11ac |
| CAPWAP | Layer 2 network topology between an AP and AC Enable an AP to automatically discover an accessible AC Enable an AP to automatically download configurations from an AC |
| Roaming | Intra-AC roaming |
| Forwarding | Local forwarding Centralized forwarding |
| Wireless QoS | AP-based bandwidth control WLAN-based bandwidth control User-based static and smart speed control Fair balancing |
| User Isolation | WLAN-based user isolation |
| User Management | Access control based on SSID user number |
| RF Management | Country code configuration Manual configuration of transmitting powerManual configuration of working channelAutomatically allocation of working channel Scheduled reallocation of wireless channel |
| PoE Protocol | IEEE 802.3af |
| WAN Port Function | Dynamic IP Static IP PPPoE IP/Mask configuration MTU configuration TCP MSS configuration Network bandwidth configuration Gateway address assignment NQA configuration to probe address |
| Multi-WAN Load Balancing | Distributing network traffic equally Ratio load balancing Multi-link for load balancing |
| Link Detection | Enable and disable link detection ICMP probe TCP probe |
| IP Routing | Static routing Policy-based routing |
| VPN | L2TP VPN PPTP VPN |
| DHCP Function | DHCP Server DHCP Client |
| Security | Portal Authentication PPPoE Authentication IP/MAC Authentication IP/MAC Binging Intranet Anomaly Detection Intranet Attack Protection WAN Ping Forbid Virtual AP Multiple SSIDs SSID Hiding WPA/WPA2 WPA3 WEP(WEP/WEP128) TKIP |
| QoS/ACL | Traffic supervision Congestion managementCongestion avoidance Traffic shaping IP-based speed limitTraffic classification |
| Equipment Management | Web Management TFTP FTP NTP System Log Ping |
| Performance | |
| Default Number of Manageable APs | 10 |
| Maximum Number of Manageable APs | 10 |
| Maximum Number of Configurable APs | 10 |
| Users Capacity | 1K |
| Firewall | 500 Mbps |
| Encryption | 500 Mbps |
| Forwarding Capability | 500 Mbps |
| CPU Frequency | 880 MHz |
| Processor | Dual core |
| MTBF | 40,000 hours |
| Memory | 256 MB |
| Flash | 16 MB |
| Packet Buffer Size | 2 MB |
| MAC Address List | 1024 |
| Entries of MAC Address Filtering Table | 32 |
| IPv4 Forwarding | 1 Gbps |
| Static Routes | 200 |
| Max. Number of Static DNS Records | 256 |
| Max. Number of DDNS Records | 4 |
| Static ARP | 1K |
| Dynamic ARP | 2K |
| ACL | 1K |
| L2TP Users | 128 |
| Max. Number of Tunnels | 128 |
| Max. Number of Sessions | 128 |
| Max. Number of Concurrent Connections | 200K |
| New Connections | 6K |
| Max. Number of Virtual Servers | 100 |
| Max. Number of Port Triggering | 20 |
| Aging Time of Port Triggering | 10 min |
| Number of NAT | 30 |
| General | |
| Operating Temperature | –20 °C to +55 °C |
| Operating Humidity | 5%–95% (RH), non-condensing |
| Storage Temperature | –40 °C to +70 °C |
| Storage Humidity | 5%–95% (RH), non-condensing |
| Statics Protection | Air discharge: 8 kV; Contact discharge: 6 kV |
| Lighting Protection | Common mode: 2 kV |
| Net Weight | 0.46 kg |
| Gross Weight | 0.98 kg |
| Product Dimensions | 190 mm × 97.5 mm × 29.5 mm |
| Packaging Dimensions | 225 mm × 216mm × 66mm |
| Installation | Desktop mount |
| Certifications | CE; FCC |
